Relationships between linear-quadratic parameters for cells irradiated in the presence and absence of cisplatin
- Authors: Konobeev I.A.1, Kurachenko Y.A.2, Sheino I.N.1
-
Affiliations:
- Burnasyan Federal Medical Biophysical Center
- Leypunsky Institute for Physics and Power Engineering
- Issue: Vol 30, No 2 (2026): PHISIOLOGY. EXPERIMENTAL PHYSIOLOGY
- Pages: 269-282
- Section: ONCOLOGY
- URL: https://journals.rudn.ru/medicine/article/view/50521
- DOI: https://doi.org/10.22363/2313-0245-2025-30-2-269-282
- EDN: https://elibrary.ru/GXUMTV
- ID: 50521
Cite item
Full Text
Abstract
Relevance. According to experimental data, administration of the drug cisplatin into the tumor during radiation therapy can increase its effectiveness. To date, there is no model that can predict the effectiveness of such therapy. The development of such a model is an important task for planning therapy. The goal of this work is to find analytical relationships for the survival of cells exposed to the combined effect of radiation and cisplatin in vitro. Materials and methods. Based on digitized experimental data on cell survival from a number of publicly published works, the corresponding linear-quadratic (LQ) approximation coefficients for survival were found for irradiation without the drug \( \alpha_R , \beta_R \), and for combined exposure to radiation and cisplatin \( \alpha_{RC} , \beta_{RC} \). Next, a regression analysis of the resulting set of coefficients and cell survival when exposed to cisplatin alone \( S_C \) was performed. Results and Discussion.\( \alpha_{RC} \) was found to be statistically dependent on \( \alpha_R, \beta_R \) and \( S_C \). This dependence could be described by several models, the best of which in terms of a number of indicators was \( \alpha_{RC} = \alpha_R + \alpha_R \ln S_C \), where \( \alpha = -4.27 \pm 0.57 \) is a parameter that is the same for all cell types and experimental conditions. It was found that \( \beta_{RC} \) is statistically dependent on \( \beta_R \). No signs of dependence of \( \beta_{RC} \) on \( \alpha_R \) and \( S_C \) were found. The best model for \( \beta_{RC} \) was \( \beta_{RC} = \beta_R \). These models are simple, but they allow predicting the value of cell survival under the combined effect of radiation and cisplatin \( S_{RC} \) from the values \( \alpha_R , \beta_R \) and \( S_C \) only approximately. The obtained models are collated with kinetic equations and a mechanistic interpretation is given, which is based on the hypothesis of a decrease in the rate of recovery of cells from potentially lethal lesions r , with an increase in the radiation dose and cisplatin concentration. Conclusion. The type of statistical dependence of LQ coefficients \( \alpha_{RC} \) and \( \beta_{RC} \) on \( \alpha_R , \beta_R \) and \( S_C \) has been found. In the case of high toxicity of cisplatin (low values of \( S_C \)), the combination of the above-mentioned models for \( \alpha_{RC} \) and \( \beta_{RC} \) allows to make a useful for practical application prediction of cell survival \( S_{RC} \). The results of this work will help for the future construction of more complex models of the combined effects of radiation and cisplatin, and may also have practical application in the case mentioned above.
About the authors
Ivan A. Konobeev
Burnasyan Federal Medical Biophysical Center
Author for correspondence.
Email: beo0@mail.ru
ORCID iD: 0009-0008-0938-9645
SPIN-code: 7289-8433
Yurij A. Kurachenko
Leypunsky Institute for Physics and Power Engineering
Email: beo0@mail.ru
Igor N. Sheino
Burnasyan Federal Medical Biophysical Center
Email: beo0@mail.ru
ORCID iD: 0000-0003-0114-4420
SPIN-code: 7374-7849
References
- Cisplatin. The American society of health-system pharmacists. Available from: https://www.drugs.com/monograph/cisplatin.html. Accessed: March 5, 2025.
- Gitelson DG, Rogov DA, Vasiliev AE, Gitelson EA. The basics of chemoembolization. RUDN Journal of Medicine. 2017;21(2):194-204. doi: 10.22363/2313-0245-2017-21-2-194-204
- Oun R, Moussa YE, Wheate NJ. The side effects of platinum-based chemotherapy drugs: a review for chemists. Dalton Transactions. 2018;47(19):6645-6653. doi: 10.1039/c8dt00838h
- Gorodetsky R, Levy-Agababa F, Mou X, Vexler AM. Combination of cisplatin and radiation in cell culture: effect of duration of exposure to drug and timing of irradiation. International Journal of Cancer. 1998;75(4):635-642. doi: 10.1002/(sici)1097-0215(19980209)75:4<635::aid-ijc23>3.0.co;2-6
- Liu M, Ma S, Liu M, Hou Y, Liang B, Su X, Liu X. Synergistic killing of lung cancer cells by cisplatin and radiation via autophagy and apoptosis. Oncology Letters. 2014;7(6):1903-1910. doi: 10.3892/ol.2014.2049
- Groen HJ, Sleijfer S, Meijer C, Kampinga HH, Konings AW, De Vries EG, Mulder NH. Carboplatin- and cisplatin-induced potentiation of moderate-dose radiation cytotoxicity in human lung cancer cell lines. British Journal of Cancer. 1995;72(6):1406-1411. doi: 10.1038/bjc.1995.522
- Zhurakovskaya GP, Petin VG. Principles of mathematical modeling of combined effects in biology and medicine (literature review). Radiatsiya i risk. 2015;24(1):61-73. (in Russian).
- Franken NA, Oei AL, Kok HP, Rodermond HM, Sminia P, Crezee J, Stalpers LJ, Barendsen GW. Cell survival and radiosensitisation: modulation of the linear and quadratic parameters of the LQ model (Review). International journal of oncology. 2013;42(5):1501-1515. doi: 10.3892/ijo.2013.1857
- McMahon SJ, Prise KM. Mechanistic Modelling of Radiation Responses. Cancers (Basel). 2019;11(2):205. doi: 10.3390/cancers11020205
- Murthy AK, Rossof AH, Anderson KM, Hendrickson FR. Cytotoxicity and influence on radiation dose response curve of cis-diamminedichloroplatinum II (cis-DDP). International journal of radiation oncology, biology, physics. 1979;5(8):1411-1415. doi: 10.1016/0360-3016(79)90680-1
- Begg AC, van der Kolk PJ, Dewit L, Bartelink H. Radiosensitization by cisplatin of RIF1 tumour cells in vitro. International journal of radiation biology and related studies in physics, chemistry and medicine. 1986;50(5):871-884. doi: 10.1080/09553008614551291
- Carde P, Laval F. Effect of cis-dichlorodiammine platinum II and X rays on mammalian cell survival. International journal of radiation oncology, biology, physics. 1981;7(7):929-933. doi: 10.1016/0360-3016(81)90011-0
- Petrovic M, Popovic S, Baskic D, Todorovic M, Djurdjevic P, Ristic-Fira A, Keta O, Petkovic V, Koricanac L, Stojkovic D, Jevtic V, Trifunovic S, Todorovic D. The effects of newly synthesized platinum(IV) complexes on cytotoxicity and radiosensitization of human tumour cells in vitro. Anticancer research. 2020;40(9):5001-5013. doi: 10.21873/anticanres.14503
- Caney C, Singh G, Lukka H, Rainbow AJ. Combined gamma-irradiation and subsequent cisplatin treatment in human squamous carcinoma cell lines sensitive and resistant to cisplatin. International journal of radiation biology. 2004;80(4):291-299. doi: 10.1080/09553000410001679767
- Fehlauer F, Barten-Van Rijbroek AD, Stalpers LJ, Leenstra S, Lindeman J, Tjahja I, Troost D, Wolbers JG, van der Valk P, Sminia P. Additive cytotoxic effect of cisplatin and X-irradiation on human glioma cell cultures derived from biopsy-tissue. Journal of cancer research and clinical oncology. 2000;126(12):711-716. doi: 10.1007/pl00008476
- Holford N, Sheiner L. Understanding the dose-effect relationship: clinical application of pharmacokinetic-pharmacodynamic models. Clinical pharmacokinetics. 1981;6:429-453. doi: 10.2165/00003088-198106060-00002
- McMahon SJ. The linear quadratic model: usage, interpretation and challenges. Physics in medicine and biology. 2018;64(1):01TR01. doi: 10.1088/1361-6560/aaf26a
- Shapiro SS, Wilk MB. An analysis of variance test for normality (complete samples). Biometrika. 1965;52(3-4):591-611. doi: 10.1093/biomet/52.3-4.591
- Kanji Gopal K. 100 Statistical Tests. 3rd ed. London: SAGE Publications Ltd.; 1994.
- Rencher AC, Christensen WF. Methods of multivariate analysis. 3rd ed. John Wiley and Sons; 2012.
- Efron B, Tibshirani R. An introduction to the bootstrap. 1st ed. Boca Raton, Florida: Chapman and Hall/CRC; 1993.
- Hawkins RB, Inaniwa T. A microdosimetric-kinetic model for cell killing by protracted continuous irradiation including dependence on LET I: repair in cultured mammalian cells. Journal of radiation research. 2013;180(6):584-594. doi: 10.1667/RR13257.1
- Tobias CA. The repair-misrepair model in radiobiology: comparison to other models. Radiation research supplement. 1985;8:S77-95.
- Curtis SB. Lethal and potentially lethal lesions induced by radiation - a unified repair model. Journal of radiation research. 1986;106(2):252-270.
- Reddy NM, Mayer PJ, Lange CS. The saturated repair kinetics of Chinese hamster V79 cells suggests a damage accumulation - interaction model of cell killing. Journal of radiation research. 1990;121(3):304-311.
- Wilson GD, Bentzen SM, Harari PM. Biologic basis for combining drugs with radiation. Seminars in Radiation Oncology. 2006;16(1):2-9. doi: 10.1016/j.semradonc.2005.08.001
